uPVC sliding Monorail Window
uPVC sliding Monorail Window

uPVC sliding Monorail Window

Price 1000 INR/ Square Feet

uPVC sliding Monorail Window Specification

  • Surface Finish
  • Glossy / Matte as per requirement
  • Weather Resistance
  • Yes
  • Width
  • Customizable; typically 600 mm to 2400 mm per panel
  • Glass Thickness
  • 5 mm to 24 mm (single or insulated unit)
  • Finish Type
  • Smooth UV-resistant finish
  • Security Features
  • Strong locking, reinforced frame, anti-lift design
  • Anti Corrosion
  • Yes, corrosion-resistant profiles and hardware
  • Load Capacity
  • Up to 60 kg per sliding panel
  • Capacity
  • Designed for 1-2 operable sliding panels
  • Glass Type
  • Single/Double Glazed Toughened Glass
  • Function
  • Daylight, Ventilation, Weather Protection
  • Thickness
  • 2.5 mm - 3.0 mm (profile wall thickness)
  • Height
  • Customizable; up to 2400 mm
  • Standard
  • Conforms to EN 12608, IS 16044 standards
  • Tensile Strength
  • >3500 N
  • Usage & Applications
  • Living rooms, bedrooms, offices, balconies
  • Operation Type
  • Horizontal sliding
  • Operating Temperature
  • -20C to 60C
  • Mesh Type
  • High-quality fiber mesh or stainless steel optional
  • Coating Type
  • UV-resistant and anti-fade coating
  • Product Type
  • uPVC Sliding Window
  • Material
  • Unplasticized Polyvinyl Chloride (uPVC) and glass
  • Screen Netting Material
  • Fiber mesh / Stainless steel (optional)
  • Size
  • Custom as per requirement; standard options available
  • Weight
  • Dependent on size; average 20-40 kg per unit
  • Color
  • White, Grey, Mahogany, Golden Oak, custom on request
  • Application
  • Residential, Commercial and Industrial windows
  • Product Model
  • uPVC Sliding Monorail Series
  • Window Type
  • Sliding Monorail Window
  • Mounting Type
  • Wall mount / Frame mount
  • Design Type
  • Slim profile, modern aesthetics
  • Installation Type
  • Recessed or Surface mount
  • Locking Type
  • Multi-point locking system
  • Fire Rating
  • Self-extinguishing, Class B1 as per DIN 4102
  • Maintenance
  • Low, requires only periodic cleaning
  • Frame Reinforcement
  • Galvanized steel reinforcement inside uPVC profile
  • Accessories Included
  • Handles, stoppers, mesh frame (optional)
  • Glazing Bead Type
  • Co-extruded for secure fitment
  • Sound Insulation
  • 35-40 dB with double glazing
  • Water Tightness
  • Tested for up to 300 Pa
  • Hardware Configuration
  • Heavy-duty rollers and SS handles
  • Visible Light Transmission
  • Over 75% (with standard clear glass)
  • Wind Load Resistance
  • Tested up to 2.0 kPa (can withstand high wind pressures)
  • Insect Resistance
  • Yes, with mesh and tight frame joints
  • Opening Pattern
  • One fixed & one/two sliding panels
  • Durability
  • Minimum 20 years under normal usage
  • Sealing Type
  • Double sealing with EPDM gaskets
  • Air Permeability
  • Class 3 as per EN 12207
  • Eco Friendliness
  • Lead-free, recyclable material
  • Glass Spacer Type
  • Aluminum/Plastic, desiccant filled for IGU
  • Corner Construction
  • Fusion-welded for extra strength


uPVC sliding Monorail Window Trade Information

  • Minimum Order Quantity
  • 10 Square Feet
  • Supply Ability
  • 500 Per Day
  • Delivery Time
  • 1-3 Days


About uPVC sliding Monorail Window



Order Today and experience the ace of modern window solutions with our uPVC Sliding Monorail Window. Engineered for invincible performance, this immaculate window boasts wind load resistance up to 2.0 kPa, unbeatable sound insulation (35-40 dB), and Class 3 air permeability. Featuring double-sealing EPDM gaskets, heavy-duty hardware, and galvanized steel reinforcement, it ensures lasting durability (minimum 20 years). Enjoy a sleek, eco-friendly profile with over 75% visible light transmission and advanced security features-all at the lowest price. Unbeatable Price guaranteed on custom sizes and finishes!

Versatile Usage and Seamless Application

The uPVC Sliding Monorail Window is perfect for residential spaces like living rooms, bedrooms, and balconies, as well as commercial and industrial applications. Its smooth horizontal operation makes it ideal for areas requiring daylight, natural ventilation, weather protection, and impressive soundproofing. With easy recessed or surface mounting, this window can be seamlessly integrated into new builds or retrofitted to existing structures, accommodating varied installation needs across homes, offices, and more.


Certified Quality, Secure Shipping & Payment Assurance

Our uPVC Sliding Monorail Window conforms to EN 12608 and IS 16044 standards, ensuring world-class quality. Each unit is professionally packaged to protect against damage during secure shipping. Upon order completion, we offer flexible payment terms and guarantee safe arrival of your purchase. Your window order is handled with utmost care from production to delivery, ensuring a transparent and reliable experience every step of the way.


FAQ's of uPVC sliding Monorail Window:


Q: How does the uPVC Sliding Monorail Window provide weather protection?

A: Our window is designed with double sealing, fusion-welded corners, and tested water tightness (up to 300 Pa). These features ensure high resistance to wind, rain, and UV exposure, making it ideal for harsh weather conditions.

Q: What benefits does the double glazing offer?

A: The double glazing provides excellent sound insulation (35-40 dB) and enhances thermal efficiency, keeping interiors quiet and comfortable while reducing energy costs.

Q: Where can these monorail windows be installed?

A: They are suitable for residential, commercial, and industrial settings, including living rooms, offices, balconies, and more. Installation can be either recessed or surface-mounted, offering flexibility for various construction types.

Q: What is the process for customizing the window size and finish?

A: You may specify your dimensions and preferred color or finish during the order process. Our manufacturing team will tailor the window as per your specifications to ensure a perfect fit and impeccable style.

Q: How long does the window last and what about maintenance?

A: Our uPVC monorail windows are designed for a service life of at least 20 years with minimal maintenance. Simply clean periodically to maintain their immaculate finish and functionality.
